Schlage B250 Series Single Cylinder Gatelatch Deadbolt

SKU SC-B250-P6


30% Off


The Schlage B250P6 series is ideally suited for pool, apartment and condominium gates, utility panels and pipe chases. The Schlage B250 series is tough, reliable and has a proven design that has been the industry standard for decades. These locks are great for access control, extra heavy duty especially the deadlatch. You can use it on the heaviest gate. They are installed above the bottom lock and where a deadbolt usually is but because it’s a latch type lock rather than a deadbolt, when the door closes it will automatically re-lock.

Features and Benefits:

  • ANSI: E0122
  • Latch: 1-1/8″ x 2-1/4″, square corner faceplate, 1″ housing diameter, 9/16″ throw deadlatch
  • Single Cylinder Deadlatch (Night Latch): Deadlocking latchbolt retracted by key from outside or by inside turn unit
  • Rotating turn unit and activating hold-back feature keeps latch retracted
  • Backset: 2-3/8″ standard
  • Door Thickness: 1-1/2″ – 1-3/4″ standard cylinder
  • 6-Pin solid brass cylinder, keyed 6-pin, S123 keyway
  • ANSI/BHMA certified A156.36-2010, Grade 2 auxiliary lock
  • 6-pin S123 keyway standard with two patented nickel silver cut keys per lock
  • Strike: 1-1/8″ x 2-3/4″ square corner, T-strike

Don’t see the finish, or function or specific configuration you need? We can design, configure and build the customizations you are looking for – Just call (800) 776-3247 and our experienced support staff will help you design the systems and products you need.
